The flat bottom presents a ...

Published May 7, 2020 09:51 by Ian Pearson

The flat bottom presents a challenge, and will then require the installation of scrapers to concentrate the sludge to a sump where it can be removed. By installing a suspended sludge concentrator cone at the level of the sludge blanket, you can design to remove 90% or more of the sludge from the suspended cone. I have tried to attach two standard design options - one with scrapers and one with a suspended cone. You will probably need to incorporate both concepts into your design.

2 Comments

Hi Ian, thanks. The resolution is a bit hard to read. Much appreciated if you could upload a higher resolution version. Thanks

Published May 7, 2020 12:50 by Trudi Schifter, CEO and Founder AquaSPE

Permalink

Can you oblige by sending the drawings on my e-mail - info@patfil.com as they are not properly readable on the site.

Published May 7, 2020 11:29 by Akshay Patel

Permalink

1 Comment

you can download directly from the site

Published May 7, 2020 12:48 by Trudi Schifter, CEO and Founder AquaSPE
